JUNCTION BOX GW44114 (100X100X80) IP56 HF
Product code
3466683
Halogen-free enclosure for normal use with smooth sides GWT 650°C/TP 85°C. High mechanical protection class IK 08. The enclosure is manufactured from durable technopolymer in accordance with standards EN 60670-1 (CEI 23-48) and IEC 60670-22 (CEI 23-94). This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
ShapeSquare
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
For tube diameterOther
Number of inlets0
Inlet from the rearno
Length109 mm
Width109 mm
Depth86 mm
Connectableno
Type of housing feed-throughNone
MaterialPlastic
Product codes
SAPDBR654
STK3466683
PLC3466683
GTIN/EAN8011564763470
Manufacturer part numberGW44114
Vendor material numberGW44114
Basic information
Package measurements (L x W x H)115 x 115 x 90 mm
Package volume1.19 l
Package weight0.163 kg
Base uniteach
Package units1 / 45 / 900
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
