JUNCTION BOX GW44138 (240X190X130) IP56 HF
Product code
3466689
Halogen-free enclosure for normal use with smooth sides/clear cover GWT 650°C/TP 85°C. High mechanical protection class IK 08. The enclosure is manufactured from durable technopolymer in accordance with standards EN 60670-1 (CEI 23-48) and IEC 60670-22 (CEI 23-94). Mounting plates available for the enclosure: galvanized steel mounting plate (3466042/GW44616) and insulated plastic mounting plate (3466755/GW44626). This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
ShapeRectangular
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
For tube diameterOther
Number of inlets0
Inlet from the rearno
Length255 mm
Width201 mm
Depth138 mm
Connectableno
Type of housing feed-throughNone
MaterialPlastic
Product codes
SAPDBR660
STK3466689
PLC3466689
GTIN/EAN8011564763548
Manufacturer part numberGW44138
Vendor material numberGW44138
Basic information
Package measurements (L x W x H)260 x 205 x 143 mm
Package volume7.622 l
Package weight0.679 kg
Base uniteach
Package units1 / 12 / 144
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
