JUNCTION BOX GW44219 (300X220X180) IP56 HF

Product code
3466038
Halogen-free enclosure for normal use with smooth sides GWT 650°C/TP 85°C. High mechanical protection class IK 08. The enclosure is manufactured from durable technopolymer in accordance with standards EN 60670-1 (CEI 23-48) and IEC 60670-22 (CEI 23-94). Mounting plates are available for the enclosure: mounting plate galvanized steel (3466043/GW44617) and mounting plate insulated plastic (3466756/GW44627). This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
ShapeRectangular
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
For tube diameterOther
Number of inlets0
Inlet from the rearno
Length316 mm
Width236 mm
Depth188 mm
Connectableno
Type of housing feed-throughNone
MaterialPlastic

Product codes

SAPGCT865
STK3466038
PLC3466038
GTIN/EAN8011564013902
Manufacturer part numberGW44219
Vendor material numberGW44219

Basic information

Package measurements (L x W x H)301 x 219 x 191 mm
Package volume12.591 l
Package weight1.14 kg
Base uniteach
Package units1 / 7 / 7 / 140
Package contents
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
