JUNCTION BOX GW44280 (380X300X120) IP56

Product code
3466715
Halogen-free enclosure for special applications (e.g., floors, suspended ceilings) with smooth sides GWT 960°C/TP 85°C. High mechanical protection class IK 07. The enclosure is manufactured from durable technopolymer in accordance with standards EN 60670-1 (CEI 23-48) and IEC 60670-22 (CEI 23-94). Mounting plates are available for the enclosure: mounting plate galvanized steel (3466044/GW44618) and mounting plate insulated plastic (3466757/GW44628). This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
ShapeRectangular
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
For tube diameterOther
Number of inlets0
Inlet from the rearno
Length396 mm
Width316 mm
Depth128 mm
Connectableno
Type of housing feed-throughNone
MaterialPlastic

Product codes

SAPDBR686
STK3466715
PLC3466715
GTIN/EAN8011564229266
Manufacturer part numberGW44280
Vendor material numberGW44280

Basic information

Package measurements (L x W x H)400 x 320 x 135 mm
Package volume17.28 l
Package weight1.686 kg
Base uniteach
Package units1 / 4 / 4 / 64
Package contents
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
