JUNCTION BOX GW44418 (240X190X160) IP56 HF
Product code
3466737
Halogen-free enclosure for industrial use with smooth sides GWT 650°C/TP 110°C. High mechanical protection class IK 08. The enclosure is manufactured from durable technopolymer in accordance with standards EN 60670-1 (CEI 23-48) and IEC 60670-22 (CEI 23-94). This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
ShapeRectangular
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
For tube diameterOther
Number of inlets0
Inlet from the rearno
Length254 mm
Width200 mm
Depth167.5 mm
Connectableno
Type of housing feed-throughNone
MaterialPlastic
Product codes
SAPDBR707
STK3466737
PLC3466737
GTIN/EAN8011564014053
Manufacturer part numberGW44418
Vendor material numberGW44418
Basic information
Package measurements (L x W x H)260 x 205 x 173 mm
Package volume9.221 l
Package weight0.839 kg
Base uniteach
Package units1 / 12 / 12 / 144
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
