MCB GW92286 4X10A B-CURVE 6KA
Product code
3202387
GEWISS circuit breaker 4x10A B-curve 6kA (EN 60898) 230-400V. A fork-type busbar is suitable for this product. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Miniature circuit breaker (MCB) (EC000042)
Built-in depth72 mm
Release characteristicB
Number of poles (total)4
Number of protected poles4
Rated current10 A
Rated voltage400 V
Rated insulation voltage Ui500 V
Rated impulse withstand voltage Uimp4 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6 kA
Voltage typeAC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V6 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V20 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V10 kA
Frequency50-60 Hz
Power loss7.92 W
Product codes
SAPDBR520
STK3202387
PLC3202387
GTIN/EAN8011564057913
Manufacturer part numberGW92286
Vendor material numberGW92286
Basic information
Package measurements (L x W x H)103 x 79 x 82 mm
Package volume0.667 l
Package weight0.554 kg
Base uniteach
Package units1 / 3 / 320
Package contents–
UNSPSC39121603
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
