MODULAR ENCLOSURE SURFACE GW40071BD 54 (18X3 M IP40
Product code
3466643
The Gewiss 40CD enclosure series is a high-quality and aesthetically pleasing solution offering durable installation for any purpose. The series includes enclosures ranging from IP40 rating up to IP65 rating and IK09 impact-resistant enclosures. Door options include white smooth or transparent. The series also offers a wide range of accessories. All materials are halogen-free.
Includes connectors N/PE 2 x [(3x16) + (17x10)] N/PE 2 x [(3x16) + (17x10)].
Features
- 54 (18 x 3) modules
- IP40
- dimensions (W x H x D) 400 x 550 x 130 mm
Product details
Technical specifications
Product class (ETIM)Small distribution board (EC000214)
Mounting methodSurface mounted
Number of rows3
Width in number of modular spacings18
Type of coveringDoor
Cover modelWith notch
Transparent cover/doorno
Signal passing doorno
With lockno
Type of closurePush button
Housing materialPlastic
Inner depth48 mm
Earthing terminal blockno
Neutral terminal blockno
DIN-railyes
With mounting plateno
Product codes
SAPCZF146
STK3466643
PLC3466643
GTIN/EAN8011564896864
Manufacturer part numberGW40071BD
Vendor material numberGW40071BD
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume36.54 l
Package weight4.467 kg
Base uniteach
Package units2 / 50
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
