MODULAR ENCLOSURE SURFACE GW40101 1X4M IP65

Product code
3466600
The Gewiss 40CD enclosure series is a high-quality and aesthetically pleasing solution for durable installation in any application. The series includes enclosures ranging from IP40-rated to IP65-rated and IK09 impact-resistant enclosures. Door options include white smooth or transparent. The series also offers a wide range of accessories. All materials are halogen-free. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Small distribution board (EC000214)
Mounting methodSurface mounted
Number of rows1
Width in number of modular spacings4
Type of coveringDoor
Cover modelWith notch
Type of doorSingle
Transparent cover/dooryes
Signal passing doorno
With lockno
Type of closureOther
Housing materialPlastic
Inner depth48 mm
Earthing terminal blockno
Neutral terminal blockno
DIN-railyes

Product codes

SAPCZF134
STK3466600
PLC3466600
GTIN/EAN8011564061477
Manufacturer part numberGW40101
Vendor material numberGW40101

Basic information

Package measurements (L x W x H)210 x 145 x 100 mm
Package volume3.045 l
Package weight0.51 kg
Base uniteach
Package units1 / 19 / 285
Package contents
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
