MODULAR ENCLOSURE SURFACE GW40102BS 1X8M IP65
Product code
3466604
The Gewiss 40CD enclosure series is a high-quality and aesthetic solution offering durable installation for any application. The series includes enclosures ranging from IP40 rating up to IP65 rating and IK09 impact-resistant enclosures. Door options include white smooth or transparent. The series also offers a wide range of accessories. All materials are halogen-free.
Includes connectors N/PE (2x16) + (7x10) N/PE (2x16) + (7x10).
Features
- 1 x 8 modules
- IP65
- dimensions (W x H x D) 215 x 210 x 100 mm
Product details
Technical specifications
Product class (ETIM)Small distribution board (EC000214)
Mounting methodSurface mounted
Number of rows1
Width in number of modular spacings8
Type of coveringDoor
Cover modelWith notch
Type of doorSingle
Transparent cover/dooryes
Signal passing doorno
With lockno
Type of closureOther
Housing materialPlastic
Inner depth47 mm
Earthing terminal blockno
Neutral terminal blockno
DIN-railyes
Product codes
SAPCZF135
STK3466604
PLC3466604
GTIN/EAN8011564895430
Manufacturer part numberGW40102BS
Vendor material numberGW40102BS
Basic information
Package measurements (L x W x H)210 x 215 x 100 mm
Package volume4.515 l
Package weight0.78 kg
Base uniteach
Package units1 / 12 / 144
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
