MODULAR ENCLOSURE SURFACE GW40103 1X12M IP65

Product code
3466003
The Gewiss 40CD enclosure series is a high-quality and aesthetic solution offering durable installation for any application. The series includes enclosures ranging from IP40 rating up to IP65 rating and IK09 impact-resistant enclosures. Door options include white smooth or transparent. The series also offers a wide range of accessories. All materials are halogen-free. Note! Does not include N/PE connectors. Features - 1 x 12 modules - IP65 - Dimensions (W x H x D) 298 x 260 x 140 mm - Does not include N/PE connectors This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Small distribution board (EC000214)
Mounting methodSurface mounted
Number of rows1
Width in number of modular spacings12
Type of coveringDoor
Cover modelWith notch
Type of doorSingle
Transparent cover/dooryes
Signal passing doorno
With lockno
Type of closureOther
Housing materialPlastic
Inner depth48 mm
Earthing terminal blockno
Neutral terminal blockno
DIN-railyes

Product codes

SAPCZF124
STK3466003
PLC3466003
GTIN/EAN8011564061545
Manufacturer part numberGW40103
Vendor material numberGW40103

Basic information

Package measurements (L x W x H)0 x 0 x 0 mm
Package volume16.107 l
Package weight1.681 kg
Base uniteach
Package units6 / 150
Package contents
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
