MODULAR ENCLOSURE SURFACE GW40103BS 1X12M IP65
Product code
3466605
The Gewiss 40CD enclosure series is a high-quality and aesthetic solution offering durable installation for any application. The series includes enclosures ranging from IP40-rated to IP65-rated and IK09 impact-resistant enclosures. Door options include white smooth or transparent. The series also offers a wide range of accessories. All materials are halogen-free.
Includes connectors N/PE (3x16) + (11x10) N/PE (3x16) + (11x10).
Features
- 1 x 12 modules
- IP65
- dimensions (W x H x D) 298 x 260 x 140 mm
Product details
Technical specifications
Product class (ETIM)Small distribution board (EC000214)
Mounting methodSurface mounted
Number of rows1
Width in number of modular spacings12
Type of coveringDoor
Cover modelWith notch
Type of doorSingle
Transparent cover/dooryes
Signal passing doorno
With lockno
Type of closureOther
Housing materialPlastic
Inner depth48 mm
Earthing terminal blockno
Neutral terminal blockno
DIN-railyes
Product codes
SAPCZF136
STK3466605
PLC3466605
GTIN/EAN8011564896550
Manufacturer part numberGW40103BS
Vendor material numberGW40103BS
Basic information
Package measurements (L x W x H)300 x 265 x 140 mm
Package volume11.13 l
Package weight1.64 kg
Base uniteach
Package units1 / 6 / 90
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
