RCB 16A 30MA IP41 BLACK
Product code
3202767
Residual current device GW95526 30mA 16 A/230V IP41 Type A for flush mounting.
In case of a fault, the residual current device cuts off the power to the appliance and protects the user. Over time, old sockets wear out and may pose a significant risk of electric shock and fire. When an electrical appliance malfunctions, its accessible parts can become live and cause a life-threatening electric shock. Additionally, the insulation of faulty electrical cables may begin to leak electricity into the building structure and cause a fire. In such situations, the residual current device acts as both personal protection and fire protection. The residual current device is black, RAL 9005. This product description is an automated translation of the original Finnish description.
In case of a fault, the residual current device cuts off the power to the appliance and protects the user. Over time, old sockets wear out and may pose a significant risk of electric shock and fire. When an electrical appliance malfunctions, its accessible parts can become live and cause a life-threatening electric shock. Additionally, the insulation of faulty electrical cables may begin to leak electricity into the building structure and cause a fire. In such situations, the residual current device acts as both personal protection and fire protection. The residual current device is black, RAL 9005. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Residual current circuit breaker (RCCB) (EC000003)
Number of poles2
Rated voltage230 V
Rated current16 A
Rated fault current30 A
Mounting methodOther
Leakage current typeA
Selective protectionno
Short-time delayed trippingno
Voltage typeAC
With interlocking deviceno
Frequency50/60 Hz
Additional equipment possibleno
Degree of protection (IP)IP41
Built-in depth32 mm
Ambient temperature during operating-25-40 °C
Product codes
SAPDDA570
STK3202767
PLC3202767
GTIN/EAN8034035495380
Manufacturer part numberGW95526N
Vendor material numberGW95526N
Basic information
Package measurements (L x W x H)100 x 80 x 85 mm
Package volume0.68 l
Package weight0.17 kg
Base uniteach
Package units1 / 2 / 2 / 320
Package contents–
UNSPSC39121614
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
