RCB 16A 30MA IP41 WHITE
Product code
3202766
Residual current device GW95526 30mA 16 A/230V IP41 Type A for flush mounting.
In the event of a fault, the residual current device cuts off the power to the appliance and protects the user. Old sockets degrade over time and may pose a significant risk of electric shock and fire. When an electrical appliance fails, its accessible parts can become live and cause a life-threatening electric shock. Additionally, the insulation of faulty electrical wires may begin to leak electricity into the building structure and cause a fire. In such situations, the residual current device acts as both personal protection and fire protection. This product description is an automated translation of the original Finnish description.
In the event of a fault, the residual current device cuts off the power to the appliance and protects the user. Old sockets degrade over time and may pose a significant risk of electric shock and fire. When an electrical appliance fails, its accessible parts can become live and cause a life-threatening electric shock. Additionally, the insulation of faulty electrical wires may begin to leak electricity into the building structure and cause a fire. In such situations, the residual current device acts as both personal protection and fire protection. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Residual current circuit breaker (RCCB) (EC000003)
Number of poles2
Rated voltage230 V
Rated current16 A
Rated fault current30 A
Mounting methodOther
Leakage current typeA
Selective protectionno
Short-time delayed trippingno
Voltage typeAC
With interlocking deviceno
Frequency50/60 Hz
Additional equipment possibleno
Degree of protection (IP)IP41
Built-in depth32 mm
Ambient temperature during operating-25-40 °C
Product codes
SAPDDA569
STK3202766
PLC3202766
GTIN/EAN8034035488436
Manufacturer part numberGW95526
Vendor material numberGW95526
Basic information
Package measurements (L x W x H)102 x 83 x 85 mm
Package volume0.72 l
Package weight0.17 kg
Base uniteach
Package units1 / 2 / 320
Package contents–
UNSPSC39121614
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
