RESIDUAL CURRENT DEVICE GW90923 30MA/2X63A
Product code
3202558
ReStart Autotest automates the testing of residual current devices. If the residual current device is not tested regularly, the tripping mechanism may become stuck, which could result in the device failing to operate during a fault. ReStart Autotest automatically performs the required functional test every 28 days.
ReStart Autotest residual current devices significantly save staff working time, while maintenance costs are also reduced.
In some applications, such as solar power systems and electric vehicle charging points, type B residual current devices must be used. ReStart Autotest provides a solution even when the protected object requires a type B residual current device.
The product is compatible with a fork-type current busbar. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Residual current circuit breaker (RCCB) with auxiliary device (EC002693)
Number of poles2
Rated voltage230 V
Rated current63 A
Rated fault current0.03 A
Mounting methodDIN rail
Leakage current typeA
Selective protectionno
Short-time delayed trippingno
Short-circuit breaking capacity (Icw)10 kA
Surge current capacity3 kA
Additional equipment integratedSelftest, automatic reclosing and auxiliary switch
Additional equipment attached at deliveryMonitoring unit with automatic reclosing
Rated switch current auxiliary device63 A
Rated voltage auxiliary device230 V
Control voltage type auxiliary equipmentAC
Product codes
SAPCYL068
STK3202558
PLC3202558
GTIN/EAN8011564804838
Manufacturer part numberGW90913
Vendor material numberGW90913
Basic information
Package measurements (L x W x H)155 x 130 x 105 mm
Package volume2.116 l
Package weight0.748 kg
Base uniteach
Package units1 / 2 / 216
Package contents–
UNSPSC39121614
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
