MAGNA3 32-120 180 1X 230V PN10
Product code
4615357
MAGNA3 is an intelligent circulator pump for large heating systems; its unique AUTOADAPT and FLOWLIMIT functions make operation easy and save energy by always adjusting the pump’s performance to optimum levels. The MAGNA3 pump comes standard with alarm and operating status information for building automation integration and a 0-10 V control option. The pump features a convenient display for easy commissioning. The temperature range of the pumped fluid is -10 to +110 degrees.
Features- Optimal system performance. Set, read, and limit flow directly from the display or via Grundfos GO.
- Low operating costs. No leaking shaft seals and the best energy efficiency on the market.
- Alarm and operating status information seamlessly integrated into building automation. Relay outputs as standard.
- 0-10 V control as standard, enabling zero-flow shutdown.
- Temperature difference control and heat energy measurement possible with an external sensor.
Product details
Technical specifications
Product class (ETIM)Built-in circulation pump (EC010980)
Material pump casingCast iron
Material quality pump casingCast iron EN-GJL-250 (GG 25)
Material impeller/pump wheelOther
Material quality impeller/pump wheelOther
Volume flow rate (BEP)5.53 m³/h
Discharge head at flow rate (BEP)72.4 kPa
Max. discharge flow5.53 m³/h
Max. static height12 m
Max. operating pressure10 bar
Double pumpno
Electrical connectionOther
Number of phases1
Frequency50/60 Hz
Nominal current1.56 A
Motor power input (P1) per motor0.182 kW
Product codes
SAPCHP473
HPAC4615357
PLC4615357
GTIN/EAN5711498165908
Manufacturer part number98609707
Vendor material number98609707
Basic information
Package measurements (L x W x H)237 x 226 x 276 mm
Package volume14.783 l
Package weight6.038 kg
Base uniteach
Package units15
Package contents–
UNSPSC40151504
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB
Documents (9)
Certificates
Brochures & documents
Links
Environment and safety
Features
Availability of spare parts after discontinuation (years)2
Energy efficiency index (EEI)0.18
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)43.4736
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000435
Manufacturer
NameOy Grundfos Pumput Ab
Websitewww.grundfos.com/fi
Postal addressTrukkikuja 1, FI-01360 VANTAA, Finland
