SINGLE-STAGE PUMP GRUNDFOS TP 100-250/4-A-F-A-BQQE 400D
Product code
96109308
No product description available.
Product details
Technical specifications
Material pump casingCast iron
Material quality pump casingCast iron GG 25 (GJL-250)
Material impeller/pump wheelCast iron
Material quality impeller/pump wheelCast iron GGG 40 (GJS-400-15)
Volume flow rate (BEP)131 m³/h
Discharge head at flow rate (BEP)202.95 kPa
Max. discharge flow131 m³/h
Max. static height25 m
Max. operating pressure16 bar
Double pumpfalse
Electrical connectionTerminals
Rated voltage380 ... 420 V
Number of phases3
Frequency50 Hz
Nominal current20.5 A
Product codes
SAPCGX173
HPACCGX173
PLC96109308
GTIN/EAN5700396982854
Manufacturer part number96109308
Vendor material number96109308
Basic information
Package measurements (L x W x H)1200 x 800 x 1190 mm
Package volume1142.4 l
Package weight325 kg
Base uniteach
Package units1
Package contents–
UNSPSC40151503
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB
Documents (1)
Images
