SINGLE-STAGE PUMP GRUNDFOS TP 32-60/2-A-F-A-BQQE 400Y

TP 32-60/2 A-F-A-BQQE Single-stage, compactly coupled pump with parallel suction and pressure ports of the same diameter. The pump design is "top removable," allowing the operating head (motor, pump head, and impeller) to be detached for maintenance or repair without touching the pump casing or piping. The pump features an unbalanced rubber lip seal. The shaft seal complies with standard DIN EN 12756. Pipe connections are made with PN 6/10 DIN flanges (EN 1092-2 and ISO 7005-2). The pump is equipped with an air-cooled asynchronous motor. Liquid: Pumped liquid: Water Liquid temperature range: -25 .. 120 °C Liquid temperature during operation: 20 °C Density: 998.2 kg/m³ Technical: Pump speed: 2890 rpm Rated flow rate: 7.5 m³/h Rated head: 3.6 m Actual impeller diameter: 64 mm Shaft seal code 1: Type 2: Impeller seal face 3: Static face 4: Secondary seal: BQQE Performance tolerances: ISO9906:2012 3B Materials: Pump casing: Cast iron Pump casing: EN-JL1040 Pump casing: ASTM A48-40 B Impeller: Stainless steel Impeller: DIN W.-Nr. 1.4301 Impeller: AISI 304 Installation: Ambient temperature range: -30 .. 40 °C Maximum allowable operating pressure: 10 bar Standard flange: DIN Pipe connection: DN 32 Pump suction port: DN 32 Pump discharge port: DN 32 Pressure class: PN 6/10 Installation dimension: 220 mm Motor flange size: FT75 Electrical: Motor model: SIEMENS IE Efficiency class: NA Rated power - P2: 0.25 kW Power required by pump (P2): 0.25 kW Supply frequency: 50 Hz Rated voltage: 3 x 220-240D/380-415Y V Rated current: 1.18/0.68 A Cos phi - power factor: 0.81-0.72 Rated speed: 2800-2850 rpm Number of poles: 2 Protection class (IEC 34-5): 55 Dust/Jetting Insulation class (IEC 85): F Other: Minimum efficiency index, MEI?: 0.56 ErP status: EuP separate product Net weight: 17.5 kg Gross weight: 21 kg Shipping volume: 0.04 m³ Danish VVS No.: VVS NO 381811060 Norwegian NRF no.: NRF NO 9043528 This product description is an automated translation of the original Finnish description.
