SINGLE-STAGE PUMP GRUNDFOS TP 40-270/2-A-F-A-BQQE 400Y
Product code
98133646
No product description available.
Product details
Technical specifications
Material pump casingCast iron
Material quality pump casingCast iron GG 25 (GJL-250)
Material impeller/pump wheelStainless steel
Material quality impeller/pump wheelStainless steel 304 (1.4301)
Volume flow rate (BEP)12.5 m³/h
Discharge head at flow rate (BEP)195.1 kPa
Max. discharge flow12.5 m³/h
Max. static height27 m
Max. operating pressure16 bar
Double pumpfalse
Electrical connectionTerminals
Rated voltage380 ... 415 V
Number of phases3
FrequencyOther
Nominal current3.3 A
Product codes
SAPCGX266
HPACCGX266
PLC98133646
GTIN/EAN5711490225525
Manufacturer part number98133646
Vendor material number98133646
Basic information
Package measurements (L x W x H)400 x 300 x 744 mm
Package volume89.28 l
Package weight41.4 kg
Base uniteach
Package units1
Package contents–
UNSPSC40151503
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB
