SINGLE-STAGE PUMP GRUNDFOS TP 50-430/2-A-F-A-BQQE 400D
Product code
96087198
No product description available.
Product details
Technical specifications
Material pump casingCast iron
Material quality pump casingCast iron GG 25 (GJL-250)
Material impeller/pump wheelCast iron
Material quality impeller/pump wheelCast iron GGG 40 (GJS-400-15)
Volume flow rate (BEP)35.1 m³/h
Discharge head at flow rate (BEP)332.36 kPa
Max. discharge flow35.1 m³/h
Max. static height43 m
Max. operating pressure16 bar
Double pumpfalse
Electrical connectionTerminals
Rated voltage380 ... 415 V
Number of phases3
Frequency50 Hz
Nominal current11 A
Product codes
SAPCGX138
HPACCGX138
PLC96087198
GTIN/EAN5700395311648
Manufacturer part number96087198
Vendor material number96087198
Basic information
Package measurements (L x W x H)800 x 400 x 557 mm
Package volume178.24 l
Package weight102 kg
Base uniteach
Package units1
Package contents–
UNSPSC40151503
BrandGRUNDFOS
VendorGRUNDFOS PUMPUT OY AB
Documents (1)
Images
