CURRENT TRANSFORMER LVZW600 600/1 CL1 NH1-3
Product code
6773514
CT LV W1-3 600/5A 5VA Cl.1
Current transformer 600/5 A, suitable for installation in compact Hager fuse switchgear with high mounting rail fittings for NH1-3 sizes to save space in the panel, accuracy class 1, secondary terminals with screw connections for conductors up to 6 mm². This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Current transformer (EC002048)
ModelAttachable current transformer
Rated primary current600 A
Rated secondary current5 A
Rated secondary apparent power5 VA
Accuracy class1
Overcurrent limiting factorFS 5
Calibratedno
With contact protectionyes
Opening diameter21 mm
Snap mountingno
With copper railno
Secondary connectionScrew connection
Number of primary inputs1
Product codes
SAPCER274
STK6773514
PLC6773514
GTIN/EAN4049857123650
Manufacturer part numberLVZW600
Vendor material number6773514
Basic information
Package measurements (L x W x H)80 x 63 x 45 mm
Package volume0.227 l
Package weight0.176 kg
Base uniteach
Package units1 / 2000 / 2000
Package contents–
UNSPSC39121003
BrandHAGER
VendorUTU OY
Documents (5)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.
GWP, uniteach
Source for GWP dataEPD
