FLOOR BOX PA 200X200 BLACK
Product code
1461012
supply-unit Q06 f flooring 12mm db
Floor box cover Q06 200x200 mm for floor finish, deep black polyamide plastic, compliant with DIN EN 50085-1 and DIN 50085-2-2, includes general mounting kit, cover frame for surface mounting, adjustable installation height in steps up to 18 mm, compatible with flat floor protection FK17011, FK17035, or FK19005. Insertion length: 200 mm Insertion width: 200 mm Overall length: 219 mm Floor finish recess depth: 12 mm Minimum insertion depth: 84 mm Color: black RAL color code: 9005 Floor cleaning: dry Approvals/standards: EN50085-2-2 This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Device installation insert for subfloor installation (EC000024)
Cover modelSquare
Number of inlets1
Number of device cups2
Number of socket outlets with protective contact CEE 7/3 (type F)6
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 5P (1, 2, 3, N, PE)0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 5P (1, 2, 3, N, PE)0
With cable outlet in coveryes
Lockable coveryes
Housing materialPlastic
Material coverPlastic
With opening carpetingyes
Depth of flooring recess12 mm
Protective frame carpetingyes
ColourBlack
RAL-number9005
Product codes
SAPANT358
STK1461012
PLC1461012
GTIN/EAN4012002244982
Manufacturer part numberVQ06129005
Vendor material number1461012
Basic information
Package measurements (L x W x H)220 x 220 x 65 mm
Package volume3.146 l
Package weight1.07 kg
Base uniteach
Package units1
Package contents–
UNSPSC39131605
BrandHAGER
VendorUTU OY
