MCB NQN150 1X50A CURVE B 15KA
Product code
3263719
1-pole circuit breaker 15 kA C-curve 50 A, size 1 module. Cable protection according to IEC 60947-2. Touch protection IP2x according to DIN VDE 0106 part 100. The circuit breaker is equipped with a thermal trip mechanism for overload protection and an electromagnetic trip mechanism for short-circuit protection. Can be fitted with additional modules for rear mounting. The device is equipped with a viewing window and can be replaced from the DIN rail by releasing the DIN rail clip to the end position. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Miniature circuit breaker (MCB) (EC000042)
Built-in depth70 mm
Release characteristicB
Number of poles (total)1
Number of protected poles1
Rated current50 A
Rated voltage415 V
Rated insulation voltage Ui500 V
Rated impulse withstand voltage Uimp6 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10 kA
Voltage typeAC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V15 kA
Frequency50-60 Hz
Current limiting class3
Flush-mounted installationyes
Concurrently switching neutral conductorno
Product codes
SAPALZ947
STK3263719
PLC3263719
GTIN/EAN3250614645518
Manufacturer part numberNQN150
Vendor material number3263719
Basic information
Package measurements (L x W x H)20 x 100 x 80 mm
Package volume0.16 l
Package weight0.13 kg
Base uniteach
Package units1 / 108 / 2592
Package contents–
UNSPSC39121603
BrandHAGER
VendorUTU OY
Documents (7)
Certificates
Images
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.1681
GWP, uniteach
Source for GWP dataEPD
