MCB NQN332 3X32A CURVE B 20KA
Product code
3263735
3-pole 20kA C-curve 32A circuit breaker, 3 module size. Circuit protection in accordance with IEC 60947-2. Touch protection IP2x according to DIN VDE 0106 part 100. The circuit breaker is equipped with a thermal trip mechanism for overload protection and an electromagnetic trip mechanism for short-circuit protection. Can be fitted with additional modules for rear mounting. The device is equipped with a status window and can be replaced from a DIN rail mounting by releasing the DIN rail clip to the end position. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Miniature circuit breaker (MCB) (EC000042)
Built-in depth70 mm
Release characteristicB
Number of poles (total)3
Number of protected poles3
Rated current32 A
Rated voltage415 V
Rated insulation voltage Ui500 V
Rated impulse withstand voltage Uimp6 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10 kA
Voltage typeAC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V40 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V20 kA
Frequency50-60 Hz
Current limiting class3
Product codes
SAPALZ963
STK3263735
PLC3263735
GTIN/EAN3250614645792
Manufacturer part numberNQN332
Vendor material number3263735
Basic information
Package measurements (L x W x H)60 x 100 x 80 mm
Package volume0.48 l
Package weight0.4 kg
Base uniteach
Package units1 / 36 / 840
Package contents–
UNSPSC39121603
BrandHAGER
VendorUTU OY
Documents (5)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.2827
GWP, uniteach
Source for GWP dataEPD
