MOULDED CASE CIRCUIT BREAKER 3P 250-630A 70KA
Product code
3636536
MCCB h630 3P 70kA 630A LSI
Moulded Case Circuit Breaker h630 3P 70kA 630A LSI
Product details
Technical specifications
Product class (ETIM)Power circuit-breaker for trafo/generator/installation protection (EC000228)
Rated permanent current Iu630 A
Rated voltage220 - 690 V
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz70 kA
Overload release current setting250 - 630 A
Adjustment range undelayed short-circuit release3500 - 6300 A
Device constructionBuilt-in device fixed built-in technique
Integrated earth fault protectionno
Type of electrical connection of main circuitScrew connection
Suitable for DIN rail (top hat rail) mountingno
DIN rail (top hat rail) mounting optionalno
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
With switched-off indicatorno
Number of poles3
Product codes
SAPAME799
STK3636536
PLC3636536
GTIN/EAN3250613349615
Manufacturer part numberHED630H
Vendor material number3636536
