MOULDED CASE CIRCUIT BREAKER 3P 63-80-100A 25KA TM ADJ/FIX
Product code
3636464
MCCB X160 3P 25kA 100A
Moulded Case Circuit Breaker X160 3P 25kA 100A
Product details
Technical specifications
Product class (ETIM)Power circuit-breaker for trafo/generator/installation protection (EC000228)
Rated permanent current Iu100 A
Rated voltage220 - 415 V
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz25 kA
Overload release current setting63 - 100 A
Adjustment range short-term delayed short-circuit release0 - 0 A
Adjustment range undelayed short-circuit release1500 - 1500 A
Device constructionBuilt-in device fixed built-in technique
Integrated earth fault protectionno
Type of electrical connection of main circuitScrew connection
Suitable for DIN rail (top hat rail) mountingyes
DIN rail (top hat rail) mounting optionalno
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
With switched-off indicatoryes
Product codes
SAPAME740
STK3636464
PLC3636464
GTIN/EAN3250613130497
Manufacturer part numberHHA100H
Vendor material number3636464
Basic information
Package measurements (L x W x H)130 x 96 x 75 mm
Package volume0.936 l
Package weight1 kg
Base uniteach
Package units1 / 9 / 216
Package contents–
UNSPSC39121616
BrandHAGER
VendorUTU OY
