RCBO AFA982G 300MA A/2X32A CURVE C
Product code
3260758
Complies with DIN VDE 0664 part 20 / EN61009-1 and DIN VDE 0664 part 21 / EN61009-2-1. Touch protection according to DIN VDE 0660 part 514. Double terminals on the bottom surface for busbar and conductor connections, blue test button and fault current indication on the front surface. Easy to replace and add to busbar installations thanks to the practical DIN-rail mounting clip. Additional modules can be retrofitted to the device. The device is equipped with a hinged label window for group labeling. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Earth leakage circuit breaker (EC000905)
Number of poles (total)2
Rated voltage240 V
Rated current32 A
Rated fault current0.3 A
Leakage current typeA
Current limiting class3
Rated short-circuit breaking capacity according to IEC 60947-210 kA
Voltage typeAC
Frequency50 Hz
Release characteristicC
Overvoltage category3
Pollution degree2
Width in number of modular spacings2
Built-in depth68 mm
Degree of protection (IP)IP20
Product codes
SAPAEY952
STK3260758
PLC3260758
GTIN/EAN3250611027065
Manufacturer part numberAFA932H
Vendor material number3260758
Basic information
Package measurements (L x W x H)40 x 100 x 80 mm
Package volume0.32 l
Package weight0.24 kg
Base uniteach
Package units1 / 60 / 1440
Package contents–
UNSPSC39121614
BrandHAGER
VendorUTU OY
Documents (6)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.1055
