SCREED-FLUSH TRUNKING LID BKG BKG FE 300X1000MM REC. BLIND Z
Product code
1476718
End cap with surface recess for floor channel BKGD 300x60/80, length 1 m, galvanized steel
The cover for floor channel BKG300 with surface recess, length 1 m, is designed for dry indoor areas with dry-cleanable flooring. It allows for a floor finish thickness of up to 3 mm. Electrical connection with grounding springs is optional. Complies with standard DIN EN 50085-2-2. Ideal for floor channels with floor leveling compound. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Cover for subfloor installation duct flush floor open (EC000894)
Width300 mm
Length999 mm
Material thickness3 mm
Mounting openingNone
Number of mounting openings0
Type of cable outletSeparate cable outlet
Cover modelTrough
MaterialOther
Surface protectionGalvanised
Product codes
SAPDMN556
STK1476718
PLC1476718
GTIN/EAN4012740030571
Manufacturer part numberBKG3002W3
Vendor material number1476718
Basic information
Package measurements (L x W x H)1000 x 290 x 8 mm
Package volume2.32 l
Package weight4.46 kg
Base uniteach
Package units1 / 60
Package contents–
UNSPSC39131712
BrandHAGER
VendorUTU OY
