SOCKET OUTLET S.1 2S/16A/IP20 2X 1.5DB UKJ ALU
Product code
2507740
Surface-mountable 2-part socket outlet with a low central plate and touch protection for dry location combined installation with a separate cover plate. The socket base is equipped with two chain connectors for chaining additional supply or control circuit conductors. Installation in 1.5 size junction boxes. Surface mounting is possible with the separate orderable surface mounting frame 6310821404. Color: matte painted aluminum. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Socket outlet (EC000125)
ModelSocket outlet with protective contact CEE 7/3 (type F)
Number of active contacts (round)2
Number of active contacts (flat)0
Number of socket outlets switchable0
Imprint/indicationNone
Connection typePush-in clamp
With hinged lidno
With enhanced contact protectionyes
ColourAluminium
RAL-number (similar)9006
Transparentno
Lockableno
Eject-mechanismno
With function lightingno
With orientation lightingno
Product codes
SAPCFZ105
STK2507740
PLC2507740
GTIN/EAN4011334452126
Manufacturer part number47791404
Vendor material number2507740
Basic information
Package measurements (L x W x H)65 x 85 x 120 mm
Package volume0.663 l
Package weight0.08 kg
Base uniteach
Package units1 / 10 / 50 / 2000
Package contents–
UNSPSC39121308
BrandHAGER
VendorUTU OY
Documents (7)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.0105
GWP, uniteach
Source for GWP dataEPD
Documents (1)
Sustainability brochures & documents
