SOCKET OUTLET W.1 1S/16A/IP55 KJ WHITE
Product code
2408732
SCHUKO socket body with hinged cover for flush/surface mounting, to be installed with a separately ordered surface mounting box or flush mounting frame. - Increased touch protection. Rated voltage 250 VAC. Rated current 16 A. Hinged cover springs made of stainless steel, quick-release latches made of ZAMAK - with spring terminals. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Socket outlet (EC000125)
ModelSocket outlet with protective contact CEE 7/3 (type F)
Concurrently switching neutral conductorno
Protective contactEarthing clips
Number of active contacts (round)2
Number of active contacts (flat)0
Number of active contacts (square)0
With signal lampno
Number of ports USB-A0
Number of ports USB-C0
Max. current rating of USB power supply0 A
Number of modules (module system)0
Number of socket outlets switchable0
Number of phases1
Imprint/indicationNone
Connection typePush-in clamp
Product codes
SAPDQC494
STK2408732
PLC2408732
GTIN/EAN3250617175609
Manufacturer part numberWNA160B
Vendor material number2408732
Basic information
Package measurements (L x W x H)81 x 81 x 64 mm
Package volume0.42 l
Package weight0.078 kg
Base uniteach
Package units1 / 36 / 1152
Package contents–
UNSPSC39121308
BrandHAGER
VendorUTU OY
