MODULE COVER SURFACE ENYBOARD KV 1512, IP54, 400VAC
Product code
3430662
ENYBOAR module enclosures are made from high-quality durable plastic and enable demanding 3-54 module installations. The enclosures have an IP54 or IP65 protection rating and Class II protection, and are approved according to standards SFS-EN 60439-3 / IEC 60439-3. The module enclosure is halogen-free and silicone-free. The enclosure is gray (RAL 7035). This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Small distribution board (EC000214)
Mounting methodSurface mounted
Number of rows1
Width in number of modular spacings12
Type of coveringDoor
Cover modelClosed
Transparent cover/dooryes
With lockno
Housing materialPlastic
Built-in depth93 mm
Inner depth114 mm
DIN-railyes
With mounting plateno
Extension possibleyes
EMC-versionno
ColourGrey
Product codes
SAPCID309
STK3430662
PLC3430662
GTIN/EAN4012591624400
Manufacturer part numberKV1512
Vendor material number3430662
Basic information
Package measurements (L x W x H)335 x 310 x 140 mm
Package volume14.539 l
Package weight1.8 kg
Base uniteach
Package units1 / 46
Package contents–
UNSPSC39121304
BrandHENSEL
VendorFSM OY FONEL SECURITY
