LED-LIGHT STRIP LEDSTRIP RX LEDSTRIP RX HDI IP20 24V 4K /M
Product code
4143504
LED strip with a short diode spacing delivers high luminous flux and excellent light quality and color rendering, Ra90. The extruded diffuser provides perfectly uniform light even in slightly lower profiles. Available in custom lengths with a cutting interval of 5 cm. Equipped with adhesive tape for quick and easy installation. Driver to be ordered separately according to installation location and desired dimming technique. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting/recessed mounting
Lamp typeLED not exchangeable
Number of nodes per meter140
Lamp power per meter19.2 W
Luminous flux per meter2000 lm
Voltage typeDC
Lamp voltage24-24 V
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Suitable for dimmeryes
Energy efficiency class of the light source according to EU regulation 2019/2015E
Rated lifetime L70/B50 at 25 °C50000 h
Degree of protection (IP)IP20
Protection class according to IEC 61140III
Product codes
SAPCIX642
STK4143504
PLC4143504
GTIN/EAN7392971137575
Manufacturer part number7505725
Vendor material number4143504
Basic information
Package measurements (L x W x H)1000 x 210 x 15 mm
Package volume0.693 l
Package weight1.15 kg
Base unitMeter
Package units1 / 15
Package contents–
UNSPSC39111544
BrandHIDE-A-LITE
VendorHIDEALITE FINLAND
Documents (9)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)14.95
GWP, unitMeter
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
Manufacturer
NameOEM Finland OY
Postal addressFiskarsinkatu 3, 20750 Turku
