LED-LIGHT STRIP LEDSTRIP RX LEDSTRIP RX HDI IP65 24V 4K /M
Product code
4143506
No product description available.
Product details
Technical specifications
Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Number of nodes per meter140
Lamp power per meter19.2 W
Luminous flux per meter1900 lm
Voltage typeDC
Lamp voltage24-24 V
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Rated lifetime L70/B50 at 25 °C50000 h
Degree of protection (IP)IP65
Protection class according to IEC 61140III
Max. system power21.1 W
Colour of lightWhite
Product codes
SAPCIX640
STK4143506
PLC4143506
GTIN/EAN7392971137599
Manufacturer part number7505727
Vendor material number4143506
Basic information
Package measurements (L x W x H)1000 x 210 x 15 mm
Package volume0.693 l
Package weight1.35 kg
Base unitMeter
Package units1 / 20
Package contents–
UNSPSC39111544
BrandHIDE-A-LITE
VendorHIDEALITE FINLAND
Documents (6)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)17.55
GWP, unitMeter
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
