LED STRIP LEDSTRIP RX LEDSTRIP LINE IP20 MLUM 4K /M
Product code
4143566
LED strip with technology that hides the LED chip and electronics beneath a uniform phosphor/silicon layer. Short distance between diodes enables uniform light without profile or dome. COB technology with high light output and excellent efficiency. Easy to customize lengths thanks to 30mm cutting intervals and seamless connections. Supplied standard on a 5m roll with self-adhesive tape and a 2m connecting cable. Driver to be ordered separately according to installation location and desired dimming technique. Maximum length 5m. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting/recessed mounting
Lamp typeLED not exchangeable
Number of nodes per meter512
Lamp power per meter10 W
Luminous flux per meter1050 lm
Voltage typeDC
Lamp voltage24-24 V
Beam angle150 °
Type of control gearLED operating device voltage-controlled
Suitable for dimmeryes
Energy efficiency class of the light source according to EU regulation 2019/2015E
Rated lifetime L70/B50 at 25 °C50000 h
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)70 %
Degree of protection (IP)IP20
Product codes
SAPCJQ510
STK4143566
PLC4143566
GTIN/EAN7392971139234
Manufacturer part number7506520
Vendor material number4143566
Basic information
Package measurements (L x W x H)1000 x 210 x 15 mm
Package volume0.693 l
Package weight0.02 kg
Base unitMeter
Package units1 / 9
Package contents–
UNSPSC39112102
BrandHIDE-A-LITE
VendorHIDEALITE FINLAND
Documents (9)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.26
GWP, unitMeter
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
Manufacturer
NameOEM Finland OY
Postal addressFiskarsinkatu 3, 20750 Turku
