DOWNLIGHT 90HV 11W 600lm 3000K suun.valk
Product code
4238472
High-quality AC LED technology-based luminaires connect directly to 230V voltage, no additional driver required. The luminaires feature die-cast aluminum housings and are equipped with a uniform diffusing opal plate. Light distribution is extremely even and uniform. The luminaires are dimmable with most R- and L-type dimmers.
Service life at 25°C (L70/B10): 400lm >49,000h, 600/900lm >50,000h, 1250lm >70,000h, and 2000lm >60,000h.
Construction Die-cast aluminum housing, protection class II, includes connection cable and junction box, chainable
Color White (RAL9016), gray (RAL9006), or black (RAL9005)
Optics Uniform diffusing opal plate, even light distribution, see product table
Enclosure rating Fixed models IP44 in closed ceiling structure, adjustable models IP20
Operating temperature -20°C / +45°C This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Downlight/spot/floodlight (EC001744)
Suitable for surface mountingno
Suitable for built-in mountingyes
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for traverse mountingno
Suitable for pedestal/floor mountingno
Suitable for light-track mountingno
Suitable for clamp-mountingno
Suitable for low voltage cable systemno
AdjustabilitySwivelling
With movement sensorno
With light sensorno
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Product codes
SAPCAP851
STK4238472
PLC4238472
GTIN/EAN8718719992500
Manufacturer part number948603MW4912
Vendor material number4238472
Basic information
Package measurements (L x W x H)120 x 110 x 110 mm
Package volume1.452 l
Package weight0.343 kg
Base uniteach
Package units1 / 45
Package contents–
UNSPSC39111515
BrandILLUXTRON
VendorHEDTEC OY AB
Documents (3)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)4.459
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
