PEX PIPE FITTING MT TA 1/2x15x2,5 TA633-315 PN10
Product code
1932515
Push-fit connector for joining PEX pipes in heating, cooling, and domestic water systems. Pressure class PN6 or PN10 or as per pipe specification. Operating temperature up to 95°C. Manufactured from zinc-resistant AMATAL brass. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Fitting with 2 connections (EC003024)
Material connection 1Brass
ShapeStraight
Model3-part
Bend angle0 °
Reducingyes
Eccentricno
System specificyes
Nominal diameter connection 11/2 inch (15)
Connection 1External thread cylindrical BSPP-G (ISO 228-1)
Outer pipe diameter connection 215 mm
Connection 2Press sleeve
Length46 mm
Max. operating pressure at 20 °C16 bar
Cappedno
With drain valveno
Product codes
SAPAMB198
HPAC1932515
PLC1932515
GTIN/EAN7318792943102
Manufacturer part number53633315
Vendor material number53633315
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.05 l
Package weight0.002 kg
Base uniteach
Package units50
Package contents–
UNSPSC40172501
BrandIMI TA
VendorIMI HYDRONIC ENGINEERING OY
