ROBOT CABLE EMC FLEX-PU-EF-CY 4G0,75 GREY D500
Product code
9210817
FLEX-PU-EF-CY is a highly flexible shielded robot cable with extremely fine conductors (class 6). Applications include machine construction as well as industrial measurement, control, and feed cable installations. The cable is also suitable for chain use. It has a durable PUR outer sheath and conductors with PVC insulation. Operating temperature is -40 °C to +80 °C (fixed installation) and -5 °C to +70 °C (moving applications). The cable's rated voltage is U0/U = 300/500 V. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Power cable < 1 kV, for moving application (EC003250)
Conductor materialCopper
Conductor surfaceBare
Nominal cross section conductor0.75 mm²
Conductor categoryClass 6 = very flexible
Number of cores4
Screen over stranding elementBraiding
Stranding elementNo
Material core insulationPolyvinyl chloride (PVC)
Core identificationNumbers
Material outer sheathOther
Colour outer sheathGrey
Torsion resistantno
Reaction-to-fire according to EN 13501-6: ClassNone
Reaction-to-fire according to EN 13501-6: Smoke productionNone
Reaction-to-fire according to EN 13501-6: Flaming droplets/particlesNone
Product codes
SAPASM120
STK9210817
PLC9210817
GTIN/EAN6438056342067
Manufacturer part number275040075
Vendor material number275040075
Basic information
Package measurements (L x W x H)1000 x 9.8 x 9.8 mm
Package volume0.097 l
Package weight0.115 kg
Base unitMeter
Package units1 / 500
Package contents–
UNSPSC26121603
BrandKABELTEC
VendorKABELTEC GMBH
Documents (2)
Brochures & documents
Links
Environment and safety
Features
Made from PVCNo
