CHANGE-OVER SWITCH KUT 463 4x63A 400V 30kW
Product code
3603048
Technical specifications
- 4-pole
- AC-23 / 230 / 400 V / 63 A / 30 kW
- AC-23 / 690 V / 40 A / 37 kW
- includes gland seals 3 x M40 (19 – 28 mm)
- includes switch KU 463N (3600733)
- changeover switch 1-0-2 positions
- steel enclosure
- 300 x 400 x 120 (l x w x h)
- Saddle cover KSLE 30 (3602968)
- in plastic enclosure (3600866)
- 3-pole (3603046)
- also available with control panel on request.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchyes
Number of switches2
Max. rated operation voltage Ue AC800 V
Rated operating voltage400-690 V
Rated permanent current Iu100 A
Rated permanent current at AC-23, 400 V63 A
Rated permanent current at AC-21, 400 V100 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw2.3 kA
Rated operation power at AC-23, 400 V30 kW
Switching power at 400 V0 kW
Product codes
SAPCYJ865
STK3603048
PLC3603048
GTIN/EAN6419410350997
Manufacturer part number35099
Vendor material number3603048
Basic information
Package measurements (L x W x H)120 x 300 x 400 mm
Package volume14.4 l
Package weight8.2 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
