GAS BURNER SWITCH KE 325MKM 3x25A 400V 11kW
Product code
3630351
Gas valve switch, IP66
3-phase, 3x25A / 11kW / 400V
IP 66,
yellow,
indicator light,
polycarbonate housing This product description is an automated translation of the original Finnish description.
3-phase, 3x25A / 11kW / 400V
IP 66,
yellow,
indicator light,
polycarbonate housing This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchno
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC690 V
Rated operating voltage400-690 V
Rated permanent current Iu25 A
Rated permanent current at AC-21, 400 V25 A
Rated operation power at AC-3, 400 V1.7 kW
Rated operation power at AC-23, 400 V11 kW
Conditioned rated short-circuit current Iq50 kA
Number of poles3
Number of auxiliary contacts as normally closed contact0
Product codes
SAPALR491
STK3630351
PLC3630351
GTIN/EAN6419410303856
Manufacturer part number30385
Vendor material number3630351
Basic information
Package measurements (L x W x H)131 x 97 x 106 mm
Package volume1.347 l
Package weight0.5 kg
Base uniteach
Package units1
Package contents–
UNSPSC41102401
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
