LOAD BREAK SWITCH KU 3800 LVK228LKX150
Product code
3602827
Made from 100% recyclable plastic Reliable switch for demanding industrial applications Supplied with LKX 150 (3602851) handle and LVK=228 shaft (3602883). Also available with yellow-red handle (LKX150 Y/R, 3602853) and different shaft lengths (100mm - 500mm) ordered separately. Available with direct handle with own electrical number (3602883 - 3602890) and product code. Auxiliary contacts available up to 8 NC + 8 NO (1.V160KU, 3600819 and 2.V160KU, 3600825). Connector and spacer plates (spacer plate VS 800, 3602856) also available with Icw 690V (1s) 28kA R.M.S value 100kA This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchno
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC1000 V
Rated operating voltage400-690 V
Rated permanent current Iu800 A
Rated permanent current at AC-23, 400 V800 A
Rated permanent current at AC-21, 400 V800 A
Rated operation power at AC-3, 400 V400 kW
Rated short-time withstand current lcw28 kA
Rated operation power at AC-23, 400 V400 kW
Switching power at 400 V400 kW
Product codes
SAPCYB321
STK3602827
PLC3602827
GTIN/EAN6419410483633
Manufacturer part number48363
Vendor material number3602827
Basic information
Package measurements (L x W x H)301 x 259 x 125 mm
Package volume9.745 l
Package weight1 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121601
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
