SAFETY SWITCH EMC KUM 325 3x25A 400V 1V 11kW
Product code
3603084
No product description available.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC800 V
Rated operating voltage400-690 V
Rated permanent current Iu63 A
Rated permanent current at AC-23, 400 V25 A
Rated permanent current at AC-21, 400 V63 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw1.7 kA
Rated operation power at AC-23, 400 V11 kW
Switching power at 400 V0 kW
Product codes
SAPADJ453
STK3603084
PLC3603084
GTIN/EAN6419410301524
Manufacturer part number30152
Vendor material number3603084
Basic information
Package measurements (L x W x H)130 x 91 x 100 mm
Package volume1.183 l
Package weight0.576 kg
Base uniteach
Package units1 / 10
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
