SAFETY SWITCH EMC KUM 625 6x25A 400V 1V 11kW
Product code
3600395
EMC-protected polycarbonate enclosure IP66
EMC-Safety switch
6-poles
AC-23/400V /25A/11kW
AC-23/690V /25A/22kW
Padlockable knob
Includes auxiliary contact: (1NO+1NC)
Includes cable glands:
4xM25EMC (11-17mm)+M16(5-10mm)
Available separately:
Aux.contact:
KU2.V (2NO+2NC) (3600491)
Rain protector:
KSL 20 (3600595) This product description is an automated translation of the original Finnish description.
EMC-Safety switch
6-poles
AC-23/400V /25A/11kW
AC-23/690V /25A/22kW
Padlockable knob
Includes auxiliary contact: (1NO+1NC)
Includes cable glands:
4xM25EMC (11-17mm)+M16(5-10mm)
Available separately:
Aux.contact:
KU2.V (2NO+2NC) (3600491)
Rain protector:
KSL 20 (3600595) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchno
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches2
Max. rated operation voltage Ue AC800 V
Rated operating voltage400-690 V
Rated permanent current Iu63 A
Rated permanent current at AC-23, 400 V25 A
Rated permanent current at AC-21, 400 V63 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw1.7 kA
Rated operation power at AC-23, 400 V11 kW
Switching power at 400 V0 kW
Product codes
SAPCIF570
STK3600395
PLC3600395
GTIN/EAN6419410303771
Manufacturer part number30377
Vendor material number3600395
Basic information
Package measurements (L x W x H)190 x 144 x 96 mm
Package volume2.627 l
Package weight0.96 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
Documents (6)
Images
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)8.016
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID22.01
