SAFETY SWITCH EMC KUM 632 6x32A 400V 1V 15kW
Product code
3600396
EMC-protected polycarbonate enclosure IP66
EMC-Safety switch (IP66)
6-pole / 6-Poles
AC-23/400V /32A/15kW
AC-23/690V /25A/22kW
Padlockable
Includes auxiliary contact (1NO/1NC)
Includes cable Glands
4xM32EMC (15-21mm) + M16(5-10mm)
Available separately:
Aux.contact:
KU2.V (2NO+2NC) (3600491)
Rain protector:
KSL 20 (3600595) This product description is an automated translation of the original Finnish description.
EMC-Safety switch (IP66)
6-pole / 6-Poles
AC-23/400V /32A/15kW
AC-23/690V /25A/22kW
Padlockable
Includes auxiliary contact (1NO/1NC)
Includes cable Glands
4xM32EMC (15-21mm) + M16(5-10mm)
Available separately:
Aux.contact:
KU2.V (2NO+2NC) (3600491)
Rain protector:
KSL 20 (3600595) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches2
Max. rated operation voltage Ue AC800 V
Rated operating voltage400-690 V
Rated permanent current Iu63 A
Rated permanent current at AC-23, 400 V32 A
Rated permanent current at AC-21, 400 V63 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw1.7 kA
Rated operation power at AC-23, 400 V15 kW
Switching power at 400 V0 kW
Product codes
SAPCIF567
STK3600396
PLC3600396
GTIN/EAN6419410328804
Manufacturer part number32880
Vendor material number3600396
Basic information
Package measurements (L x W x H)190 x 144 x 96 mm
Package volume2.627 l
Package weight0.96 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
Documents (6)
Images
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)9.4944
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID10.86
