SAFETY SWITCH KEA 325 1NO 3x25A 400V 11kW
Product code
3635127
Aluminum-enclosed 3-pole safety switch AC-23 @ 400V: 25A / 11 kW | AC-23 @ 690V: 25A / 22 kW. Includes switch: KU 325 (3609692), cable entry size to enclosure (Cu only): 1.5-16 mm², auxiliary contact: 1NO40KU (3610339), cable entries: 2 x M25 (11-17 mm) metal + 1 x M16 (5-10 mm) metal.
Protective cover KSL 12 (3602857) available separately.
This product description is an automated translation of the original Finnish description.Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC800 V
Rated operating voltage400-690 V
Rated permanent current Iu40 A
Rated permanent current at AC-23, 400 V25 A
Rated permanent current at AC-21, 400 V25 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw0 kA
Rated operation power at AC-23, 400 V11 kW
Switching power at 400 V0 kW
Product codes
SAPDCC329
STK3635127
PLC3635127
GTIN/EAN6419410298848
Manufacturer part number29884
Vendor material number3635127
Basic information
Package measurements (L x W x H)160 x 105 x 120 mm
Package volume2.016 l
Package weight0.8 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122205
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
