SAFETY SWITCH KSM 216 2x16A 400V 7,5kW
Product code
3600363
Polycarbonate housing, side-mountable IP67
Excellent protection against various chemicals / Self-extinguishing material
Safety switch
2-pole
AC-23/16A/7.5kW/400V
Lockable knob
Standard membrane seals:
2 x 20mm (Top and Bottom)
2 x 15mm (Base)
Standard vacuum breakers: 2 pcs
Cover sealable
Knob sealable in ON position
You can also order the same product with gland seals M20
KSM 216U CG (3600830) This product description is an automated translation of the original Finnish description.
Excellent protection against various chemicals / Self-extinguishing material
Safety switch
2-pole
AC-23/16A/7.5kW/400V
Lockable knob
Standard membrane seals:
2 x 20mm (Top and Bottom)
2 x 15mm (Base)
Standard vacuum breakers: 2 pcs
Cover sealable
Knob sealable in ON position
You can also order the same product with gland seals M20
KSM 216U CG (3600830) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Max. rated operation voltage Ue AC415 V
Rated operating voltage415-415 V
Rated permanent current Iu16 A
Rated permanent current at AC-21, 400 V16 A
Rated operation power at AC-23, 400 V7.5 kW
Number of poles2
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Motor drive optionalno
Product codes
SAPCBF425
STK3600363
PLC3600363
GTIN/EAN6419410328347
Manufacturer part number32834
Vendor material number3600363
Basic information
Package measurements (L x W x H)128 x 100 x 56 mm
Package volume0.717 l
Package weight0.21 kg
Base uniteach
Package units1 / 8
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
