SAFETY SWITCH KSM 425AECG 4x25A 400V 11kW
Product code
3600958
Polycarbonate enclosure, side-mountable IP67
Marking: SOLAR POWER ISOLATOR
Good resistance to various chemicals / Self-extinguishing material
Safety switch
4-pole
AC-23 / 4x25A / 11kW / 400V
Lockable knob
Includes gland seals
2 x M20 (8-13mm) and
2 x 20mm cable entries
holes 2 x 15mm (bottom)
Optional accessories:
Cover sealable
Knob sealable in ON position This product description is an automated translation of the original Finnish description.
Marking: SOLAR POWER ISOLATOR
Good resistance to various chemicals / Self-extinguishing material
Safety switch
4-pole
AC-23 / 4x25A / 11kW / 400V
Lockable knob
Includes gland seals
2 x M20 (8-13mm) and
2 x 20mm cable entries
holes 2 x 15mm (bottom)
Optional accessories:
Cover sealable
Knob sealable in ON position This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC415 V
Rated operating voltage400-415 V
Rated permanent current Iu25 A
Rated permanent current at AC-23, 400 V25 A
Rated permanent current at AC-21, 400 V25 A
Rated operation power at AC-23, 400 V11 kW
Number of poles4
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Product codes
SAPCGB214
STK3600958
PLC3600958
GTIN/EAN6419410328750
Manufacturer part number32875
Vendor material number3600958
Basic information
Package measurements (L x W x H)128 x 100 x 55.6 mm
Package volume0.712 l
Package weight0.28 kg
Base uniteach
Package units1 / 8
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.336
GWP, uniteach
Source for GWP dataco2data.fi
