SAFETY SWITCH KUA 316 3x20A 1V 7,5kW ATEx
Product code
3602802
Aluminium enclosery IP66
Safety switch ATEX (IP66)
Zone 22, Equipment Group 3
3-poles
AC-23/400V /20A/7.5kW
AC-23/690V /20A/15kW
Aluminium enclosery
Padlockable
Includes aux.contact (1NO+1NC)
Includes cable glands
2xM25EX (11-16mm) + M16EX
Available separately:
Aux.contact
KU2.V (2NO+2NC) (3600491) This product description is an automated translation of the original Finnish description.
Safety switch ATEX (IP66)
Zone 22, Equipment Group 3
3-poles
AC-23/400V /20A/7.5kW
AC-23/690V /20A/15kW
Aluminium enclosery
Padlockable
Includes aux.contact (1NO+1NC)
Includes cable glands
2xM25EX (11-16mm) + M16EX
Available separately:
Aux.contact
KU2.V (2NO+2NC) (3600491) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Explosion proof switch (EC000522)
Housing materialAluminium
ModelOff switch
Number of poles3
For Ex-zone dust22
Degree of protection (IP)IP66
Protection class according to IEC 61140III
Ambient temperature-20-40 °C
Housing colourGrey
Mounting methodSurface mounting
Height0 mm
Width0 mm
Depth0 mm
Interlockableno
Padlock lockingno
Voltage typeAC
Product codes
SAPALR445
STK3602802
PLC3602802
GTIN/EAN6419410305836
Manufacturer part number30583
Vendor material number3602802
Basic information
Package measurements (L x W x H)157 x 103 x 116 mm
Package volume1.876 l
Package weight0.8 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122209
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
