SAFETY SWITCH KUM 316AE 3x20A 400V 7,5kW
Product code
3600754
No product description available.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC800 V
Rated operating voltage400-690 V
Rated permanent current Iu40 A
Rated permanent current at AC-23, 400 V20 A
Rated permanent current at AC-21, 400 V40 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw1.7 kA
Rated operation power at AC-23, 400 V7.5 kW
Switching power at 400 V0 kW
Product codes
SAPCGB198
STK3600754
PLC3600754
GTIN/EAN6419410399989
Manufacturer part number39998
Vendor material number3600754
Basic information
Package measurements (L x W x H)135 x 100 x 110 mm
Package volume1.485 l
Package weight0.46 kg
Base uniteach
Package units1 / 10
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
