SAFETY SWITCH KUM 3200 3x200A 400V 1V 110kW
Product code
3600612
Polycarbonate enclosure IP65
Safety switch (IP65)
3-pole
AC-23/400V /200A/110kW
AC-23/690V /200A/160kW
Lockable rotary knob
Includes auxiliary contact 1NO+1NC
Flange blanks top/bottom and 2 pcs side
Available separately:
Penetrations to be ordered separately
Auxiliary contact:
KVKE2.V (2NO+2NC) (3662284)
Terminal blocks (see catalog of discontinued products) This product description is an automated translation of the original Finnish description.
Safety switch (IP65)
3-pole
AC-23/400V /200A/110kW
AC-23/690V /200A/160kW
Lockable rotary knob
Includes auxiliary contact 1NO+1NC
Flange blanks top/bottom and 2 pcs side
Available separately:
Penetrations to be ordered separately
Auxiliary contact:
KVKE2.V (2NO+2NC) (3662284)
Terminal blocks (see catalog of discontinued products) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC1000 V
Rated operating voltage400-690 V
Rated permanent current Iu200 A
Rated permanent current at AC-23, 400 V200 A
Rated permanent current at AC-21, 400 V200 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw5 kA
Rated operation power at AC-23, 400 V110 kW
Switching power at 400 V0 kW
Product codes
SAPALR414
STK3600612
PLC3600612
GTIN/EAN6419410364000
Manufacturer part number36400
Vendor material number3600612
Basic information
Package measurements (L x W x H)560 x 380 x 240 mm
Package volume51.072 l
Package weight7.8 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
