SAFETY SWITCH KUM 380 3x80A 400V 1V 45kW
Product code
3600502
Technical specifications
- L 180 x W 255 x D 100
- Polycarbonate enclosure
- IP66
- Safety switch
- 3-pole
- AC-23 / 400 V / 80 A / 45 kW
- AC-23 / 690 V / 63 A / 55 kW
- Switching device: KATKO KU 3100 load switch (3600759)
- Lockable handle
- Includes auxiliary contact 1NO+1NC 1.V160KU (3600819)
- Standard: 2xM40+M16 (Note! Max. 2 x M50 + M16 gland seals downward)
- Available separately
- Auxiliary contact 2.V160KU (3600825)
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC800 V
Rated operating voltage400-690 V
Rated permanent current Iu125 A
Rated permanent current at AC-23, 400 V80 A
Rated permanent current at AC-21, 400 V125 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw5 kA
Rated operation power at AC-23, 400 V45 kW
Switching power at 400 V0 kW
Product codes
SAPAAQ375
STK3600502
PLC3600502
GTIN/EAN6419410360200
Manufacturer part number36020
Vendor material number3600502
Basic information
Package measurements (L x W x H)270 x 190 x 145 mm
Package volume7.439 l
Package weight1.83 kg
Base uniteach
Package units1 / 5
Package contents–
UNSPSC39122205
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
Documents (6)
Images
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)20.1483
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID4.89
