SAFETY SWITCH KUT 6125 6x125A 400V 1V 55kW
Product code
3600573
Sheet steel enclosures IP65
Safety switch (IP65)
6-pole / 6-Poles
AC-23/400V / 125A / 55kW
AC-23/690V / 80A / 75kW
Padlockable
Includes 1.V160KU auxiliary contact (1NO + 1NC)
Cable information and directions to be specified when ordering.
Available separately:
Auxiliary contact:
2.V160KU (3600825) 2NO + 2NC This product description is an automated translation of the original Finnish description.
Safety switch (IP65)
6-pole / 6-Poles
AC-23/400V / 125A / 55kW
AC-23/690V / 80A / 75kW
Padlockable
Includes 1.V160KU auxiliary contact (1NO + 1NC)
Cable information and directions to be specified when ordering.
Available separately:
Auxiliary contact:
2.V160KU (3600825) 2NO + 2NC This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchyes
Version as emergency stop installationno
Version as reversing switchno
Number of switches2
Max. rated operation voltage Ue AC800 V
Rated operating voltage400-690 V
Rated permanent current Iu160 A
Rated permanent current at AC-23, 400 V125 A
Rated permanent current at AC-21, 400 V160 A
Rated operation power at AC-3, 400 V0 kW
Rated short-time withstand current lcw5 kA
Rated operation power at AC-23, 400 V55 kW
Switching power at 400 V0 kW
Product codes
SAPALR460
STK3600573
PLC3600573
GTIN/EAN6419410371305
Manufacturer part number37130
Vendor material number3600573
Basic information
Package measurements (L x W x H)400 x 300 x 162 mm
Package volume19.44 l
Package weight10 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122217
BrandKATKO
VendorKATKO OY
The country of origin stated by the supplierFinland
Documents (5)
Images
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)435.5
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID12.7
